※ 4-ports high level output up to 116 dBμV.
※ Within duplex filters, high-pass or low-pass split frequency optional.
※ Fine aluminum die cast housing, Dacromet, heat dissipation well, water-proof, radiation proof, anti-interference.
※ Optical receiver module, return optical transmitter module and the network management transponder can be hot-swappable, user upgrade conveniently.
※ 860MHz and 750MHz frequencies optional.
※ Fiber optical adapter mounted on the sending / receiving modules directly, ease of installation.
※ Each path can be fed and have a separate 60V feed port.
※ Each path has the -20dB monitor port for positive output level and return input level.
※ The positive output level, return input level and positive slope of each path can be adjusted.
※ With two grades of lighting protection. |
